PNY Quadro GP100 Graphics Card – 16 GB HBM2 4096-bit, PCI-Express 3.0 x16, SLI , HDCP 2.2 and HDMI 2.0b support, 3584 CUDA Cores, 4x Display Port, 1x DVI-D ( Dual Link ), 3-Pin 3D-Stereo | VCQGP100-P

Description

PNY Quadro GP100 Graphics Card – 16 GB HBM2 4096-bit, PCI-Express 3.0 x16, SLI , HDCP 2.2 and HDMI 2.0b support, 3584 CUDA Cores, 4x Display Port, 1x DVI-D ( Dual Link ), 3-Pin 3D-Stereo | VCQGP100-PB

NVIDIA QUADRO GP100—THE WORLD’S MOST POWERFUL WORKSTATION GRAPHICS AND COMPUTE CARD.

The NVIDIA Quadro GP100, powered by NVIDIA’s Pascal GPU architecture, is equipped with the most advanced visualization and simulation capabilities to meet the needs of the most demanding professional workflows. A single GP100 with 3580 FP32/1792 FP64 CUDA Cores has incredible horsepower to render photorealistic design concepts interactively, create extremely detailed 3D models, run intensive CAE simulations to validate designs, and evaluate design prototypes in immersive VR. You can even connect two GP100’s with NVIDIA NVLink technology to scale performance with an amazing 32GB of combined HBM2 ultra-high bandwidth memory.

Designs are becoming more complex. Media is becoming richer, higher fidelity, combining greater resolutions and complex visual effects. Scientific visualization and compute problems are larger than ever. NVIDIA Quadro Sync II compatibility enables the GP100 to build massive and sophisticated visualization, simulation and rendering environments. VR is changing all facets of entertainment, design, engineering, architecture and medicine. AI and deep learning are changing the way professionals are solving the most complex and challenging computing problems. Customers want to experience ideas, validate designs, test ideas, and simulate solutions and visualize the results as quickly as possible.

The GP100 is an excellent choice for developers who want to tap into the power of NVLink and Unified Memory to maximize their application performance. Additionally, its fast FP16 performance makes it an ideal desktop workstation solution for developers working on the latest Deep Learning/AI algorithms and frameworks.

IMAGE QUALITY

Full-Scene Antialiasing (FSAA)

Dramatically reduce visual aliasing artifacts or “jaggies” with up to 64X FSAA (128X with SLI) for unparalleled image quality and highly realistic scenes.

16K Texture and Render Processing

Texture from and render to 16K x 16K surfaces to support applications that demand the highest resolution and quality image processing.

Pascal Memory Compression

Increase bandwidth by up to 20% by reducing the amount of data fetched from memory for each frame with fourth generation, lossless delta compression.

DISPLAY FEATURES

NVIDIA Quadro MOSAIC Technology

Transparently scale the desktop and applications across up to 4 GPUs and 16 displays from a single workstation while delivering full performance and image quality.

DisplayPort 1.4

Support up to four 5K monitors at 60Hz, or dual 8K displays per card. Quadro GP100 supports HDR color for 4K at 60Hz for 10/12b HEVC decode and up to 4K at 60Hz for 10b HEVC encode. Each DisplayPort connector is capable of driving ultra-high resolutions of 4096 x 2160 at 120 Hz with 30-bit color.

NVIDIA NVIEW Advanced Desktop Software

Gain unprecedented end-user control of the desktop experience for increased productivity in single large display or multi-display environments.

NVIDIA Quadro Sync II

Synchronize the display and image output of up to 32 displays from 8 GPUs (connected through two Quadro Sync II boards) in a single system, reducing the number of machines needed to create an advanced video visualization environment.

Frame Lock Connector Latch

Each frame lock connector is designed with a self-locking retention mechanism to secure its connection with the frame lock cable to provide robust connectivity and maximum productivity.

OpenGL Quad Buffered Stereo Support

Provide a smooth and immersive 3D Stereo experience for professional applications.

Ultra High Resolution Desktop Support

Get more MOSAIC topology choices with high resolution displays devices with a 32K Max desktop size.

Professional 3D Stereo Synchronization

Robust control of stereo effects through a dedicated connection to directly synchronize 3D stereo hardware to a Quadro graphics card.

MINIMUM SYSTEM HARDWARE REQUIREMENTS

Intel Core i5, i7, Xeon or later

AMD Phenom or Opteron-class or later

PCIe x16 Gen 3 (preferred) expansion slot

2 GB or more of system memory, 8 GB recommended

200MB of available disk space for full driver installation

Blu-ray or DVD-ROM drive

Internet connection (if preferred for driver installation)

DisplayPort (preferred) or DVI compatible displays

HDMI display(s) with purchase of optional DP to HDMI adapter(s)

3D GRAPHICS ARCHITECTURE

Scalable geometry architecture

Hardware tessellation engine

NVIDIA GigaThread engine with dual copy engines

Shader Model 5.1 (OpenGL 4.5 and DirectX 12)

Up to 32K x 32K texture and render processing

Transparent multisampling and super sampling

16x angle independent anisotropic filtering

32-bit per-component floating point texture filtering and blending

64x full scene antialiasing (FSAA)/128x FSAA in SLI Mode

Decode acceleration for MPEG-2, MPEG-4 Part 2 Advanced Simple Profile, H.264, HEVC, MVC, VC1, DivX (version 3.11 and later), and Flash (10.1 and later)

Dedicated H.264 & HEVC Encoder

Blu-ray dual-stream hardware acceleration (supporting HD picture-in-picture playback)

NVIDIA GPU Boost 3.0 (Automatically improves GPU engine throughput to maximize application performance)

NVIDIA CUDA PARALLEL PROCESSING ARCHITECTURE

Pascal SM Architecture (streaming multi-processor design that delivers greater processing efficiency)

Dynamic Parallelism (GPU dynamically spawns new threads without going back to the CPU)

Mixed-precision (16-, 32- and 64-bit) computing

API support includes: CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran

Error correction codes (ECC) on graphics memory

64 KB of RAM (dedicated shared memory per SM)

ADVANCED DISPLAY FEATURES

Support for any combination of four connected displays

Four DisplayPort 1.4 outputs supporting resolutions such as 3840 x 2160 at 120Hz and 5120 x 2880 at 60Hz

DVI-D Dual Link output (up to 2560 x 1600 at 60Hz and 1920 x 1200 at 120Hz), internal 400 MHz DAC DVI-D output (analog display up to 2048 x 1536 at 85Hz)

DisplayPort to VGA, DisplayPort to DVI (single-link and dual-link) and DisplayPort to HDMI adapters optionally available (resolution support based on dongle specifications)

HDR support over DisplayPort 1.4 (SMPTE 2084/2086, BT. 2020) (4K at 60Hz 10b/12b HEVC Decode, 4K at 60Hz 10b HEVC Encode)

HDCP 2.2 support over DisplayPort, DVI and HDMI connectors

12-bit internal display pipeline (hardware support for 12-bit scanout on supported panels, applications and connection)

NVIDIA 3D Vision technology, 3D DLP, Interleaved, and other 3D stereo format support

Full OpenGL quad buffered stereo support

Underscan/overscan compensation and hardware scaling

NVIDIA NVIEW multi-display technology

Support for large-scale, ultra-high resolution visualization using the NVIDIA SVS platform which includes NVIDIA MOSAIC, NVIDIA Quadro Sync II and NVIDIA Warp/Blend technologies

Turnkey Quadro GP100 + Quadro Sync II bundles available

DISPLAYPORT AND HDMI DIGITAL AUDIO

Support for the following audio modes: Dolby Digital (AC3), DTS 5.1, Multi-channel (7.1) LPCM, Dolby Digital Plus (DD+), and MPEG-2/MPEG-4 AAC

Data rates of 44.1 KHz, 48 KHz, 88.2 KHz, 96 KHz, 176 KHz, and 192 KHz

Word sizes of 16-bit, 20-bit, and 24-bit

PACKAGE CONTAINS

NVIDIA Quadro GP000 professional graphics board

DisplayPort to DVI-D SL adapters

Auxiliary power cable

Software installation disc for Windows 10, 8.1, 8, and 7 (64- and 32-bit)

Printed Quick Start Guide

SPECIFICIATIONS

Peak Double Precision FP64 Performance

5.2 TFLOPS

Peak Single Precision FP32 Performance

10.3 TFLOPS

Peak Half Precision FP16 Performance

20.7 TFLOPS

Multi-GPU Scalability

NVLink (2-way) or SLI HB

GPU Memory

16 GB HBM2

Memory Interface

4096-bit

Memory Bandwidth

717 GB/s

System Interface

PCI Express 3.0 x16

Maximum Power Consumption

235W
Quadro Power Guidelines

Energy Star Enabling

Yes

Thermal Solution

Ultra-quiet active fansink

Form Factor

4.40” H x 10.50” L, Dual Slot

Display Connectors

DP 1.4 (4) + DVI-D DL (1) + Stereo

DisplayPort with Audio

Yes

DVI-D Single-Link Connector

Via included adapter

HDMI Support

Via optional adapters

VGA Support

Via optional adapters

Number of Displays Supported

4

Maximum DP 1.4 Resolution

HDR 7680 x 4320 at 30Hz (30-bit color)
Quadro and NVS Display Resolution Support

5K Display Support

HDR 5120 x 2880 at 60Hz (30-bit color)

4K Display Support

HDR 4096 x 2160 at 60Hz or 3840 x 2160 at 60Hz

Maximum DVI-D DL Resolution

2560 x 1600 at 60Hz via 3rd party adapter

Maximum DVI-D SL Resolution

1920 x 1200 at 60Hz via optional adapter

HDCP Support

Yes

Quadro Sync II Compatible

Yes (Frame Lock and Genlock)

NVIDIA GPU Direct Compatible

Yes

Graphics APIs

Shader Model 5.1, OpenGL 4.5, DirectX 12.0, Vulkan 1.0

Compute APIs

CUDA, DirectCompute, OpenCL

NVIEW

Yes

NVIDIA MOSAIC

Yes (Windows 10, 8.1, 8, 7, and Linux)
